CPD35｜5Ton Upgraded Heavy-Duty Lithium Forklift: Strengthened counterweight and body structure with enhanced anti-tipping stability, designed for long-term heavy-load stacking of steel materials, mechanical raw materials and stone goods.
Product Introduction
CPD35 is upgraded heavy-load model based on CPD30, rated load up to 3500kg. Reinforced counterweight and thickened chassis improve anti-tipping performance under full heavy load. Equipped with 80V 280Ah high-capacity lithium battery, stable power output during long-time heavy lifting, ideal for factories with frequent heavy cargo stacking work.
Core Product Highlights
Standard & Optional Configurations
Standard Configuration
Optional Configuration
Technical Parameter Table
| Item | Specification |
| Model | CPD35 |
| Drive Type | Electric AC Drive |
| Operation Type | Seat-type |
| Rated Load Capacity | 3500kg |
| Load Center Distance | 500mm |
| Total Service Weight (with battery) | 5600kg |
| Tire Type | Solid Elastic Tire |
| Mast Height (Fully Lowered) | 2105mm |
| Free Lift Height | 130mm |
| Standard Mast Lifting Height | 3000mm |
| Overhead Guard Height | 2215mm |
| Overall Length | 3670mm |
| Overall Length (Without Forks) | 2600mm |
| Overall Width | 1360mm |
| Fork Size (Thickness/Width/Length) | 50/125/1070mm |
| Min Ground Clearance (Mast) | 110mm |
| Min Ground Clearance (Frame) | 130mm |
| Minimum Turning Radius | 2270mm |
| Travel Speed (Loaded / Unloaded) | 15km/h / 16km/h |
| Lifting Speed (Loaded / Unloaded) | 380mm/s / 450mm/s |
| Lowering Speed (Loaded / Unloaded) | 550mm/s / 450mm/s |
| Max Gradeability (Loaded / Unloaded) | 15% / 20% |
Application Scenarios
Steel product warehouses, machinery manufacturing workshops, large raw material storage, stone processing yards.
Service Promise
Free spare parts kit for bulk orders, 24-hour overseas technical online support.
Customization & Delivery
Custom mast height, fork length and attachments available. Standard lead time 7-15 working days, CE & ISO certified for global export.
